VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel

VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel
VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel

تصویر بزرگ :  VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel

جزئیات محصول:
محل منبع: چین
نام تجاری: GNEE
گواهی: SGS
پرداخت:
مقدار حداقل تعداد سفارش: ≥1Sets
قیمت: According to the product
جزئیات بسته بندی: requst/سفارشی سازی مشتری
شرایط پرداخت: L/C، D/A، D/P، T/T، وسترن یونیون، مانی گرام
مخاطب

VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel

شرح
طول: 6058 میلی متر کلمات کلیدی: ژنراتور اکسیژن VPSA
کلمه کلیدی: کارخانه اکسیژن فشار: 0.1-0.5 مگاپاسکال
ساختار: VPSA Oxygen Generator استفاده صنعتی استاندارد: asml ， ce ， gb
خروجی نیتروژن: 160 نیوتن متر مکعب در ساعت مواد مخدر بیرونی: فولاد
محتوای نفتی: بدون روغن، بدون چربی برنامه: صنعتی، پزشکی، تصفیه فاضلاب، آبزی پروری، تولید ازن، خمیر و کاغذ، صنایع شیشه، صنایع شیمیایی، صنایع غذا
رنگ: روشن یا سفارشی مخزن اکسیژن: مخزن اکسیژن 15000 لیتری
برجسته کردن:

160Nm3/hr Nitrogen Output VPSA Oxygen Generator,15000Liters Liquid Oxygen Tank Oxygen Plant,Carbon Steel Outer Vessel VPSA Oxygen Production Line

,

15000Liters Liquid Oxygen Tank Oxygen Plant

,

Carbon Steel Outer Vessel VPSA Oxygen Production Line

Long Service Life Oxygen Production Line Applied to Industrial VPSA Oxygen Generator
Relying on the selective adsorption capacity of molecular sieves for gases, VPSA Oxygen Generator achieves air separation for oxygen production. Its working process is to adsorb nitrogen at low pressure and desorb and regenerate under vacuum conditions, cyclically producing oxygen with a purity of 90%-95%. The equipment adopts an intelligent control system to automatically adjust parameters, and its modular design supports flexible expansion, which is suitable for various needs such as industrial oxygen-enriched combustion and medical oxygen supply.
Main technical parameters of VPSA oxygen production: Purity 80%
Model specification VPSA-500 VPSA-1000 VPSA-2000 VPSA-3000 VPSA-4500 VPSA-6250 VPSA-7500
Gas production Nm3/h 500 1000 2000 3000 4500 6250 7500
Voltage 10kv 10kv 10kv 10kv 10kv 10kv 10kv
Installed power KW 250 435 715 1120 1600 2240 2500
Valve gas consumption m3/min 1.0 1.5 2.0 3.0 5.0 6.0 6.5
Cooling water circulation m3/h 20 40 80 110 120 130 140
Soft water consumption m3/h 1.92 2.7 2.88 3.9 4.2 4.5 4.8
Main technical parameters of VPSA oxygen production: Purity 93%
Model specification VPSA-200 VPSA-300 VPSA-400 VPSA-500 VPSA-600 VPSA-800 VPSA-1000
Gas production Nm3/h 200 300 400 500 600 800 1000
Voltage 380v 380v 380v 380v 380v 10kv 10kv
Installed power KW 120 165 200 270 317 380 450
Valve gas consumption m3/min 0.5 0.7 0.9 1.1 1.4 1.6 2.0
Cooling water circulation m3/h 11 15 20 26 30 38 55
Soft water consumption m3/h 1.2 1.8 1.98 2.1 2.1 2.4 2.7
Main technical parameters of VPSA oxygen production: Purity 93%
Model specification VPS-1200 VPS-1600 VPS-2000 VPS-3000 VPS-3600 VPS-4500 VPS-5500
Gas production Nm3/h 1200 1600 2000 3000 3600 4500 5500
Voltage 10kv 10kv 10kv 10kv 10kv 10kv 10kv
Installed power KW 565 715 1000 1250 1600 2000 2500
Valve gas consumption m3/min 2.0 2.4 3.0 3.3 4.2 5.5 6.5
Cooling water circulation m3/h 62 90 100 110 120 130 140
Soft water consumption m3/h 2.7 2.88 3.3 3.6 4.2 4.5 4.8
VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel 0 VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel 1 VPSA Oxygen Generator with 160Nm3/hr Nitrogen Output 15000Liters Liquid Oxygen Tank and Carbon Steel Outer Vessel 2
Detailed Maintenance Practices
Daily Maintenance
  • Check pressure gauge, flow meter, and purity analyzer readings every shift (8 hours)
  • Record operational data in the log
  • Clean air pre-filter with compressed air (0.4-0.6MPa) to remove dust and debris
Weekly Maintenance
  • Inspect seals of adsorption tower, pipelines, and valves for air leakage using soapy water test
  • Check blower and vacuum pump noise/vibration (normal ≤85dB(A))
  • Inspect lubricating system oil level and quality
Monthly Maintenance
  • Calibrate oxygen purity sensor using standard gas cylinder (93% or 95% purity)
  • Test pressure relief valve functionality
  • Inspect electrical connections for looseness
  • Clean motor and control cabinet heat dissipation fins
Annual Maintenance
  • Disassemble and clean air pre-treatment system components
  • Inspect molecular sieve condition (replace if caked or discolored)
  • Conduct comprehensive inspection of blower and vacuum pump
  • Calibrate all instruments and sensors
Maintenance of Critical Components
Molecular Sieve
  • Ensure air pre-treatment system maintains dew point ≤-40°C
  • Fill adsorption tower with nitrogen if equipment unused for >7 days
  • Use same type (lithium-based or zeolite) when replacing
  • Perform replacements in dry environment
PLC Control System
  • Keep control cabinet clean and dry
  • Regularly backup system parameters
  • Inspect wiring harness annually for aging/damage
  • Update software per manufacturer recommendations
Blower and Vacuum Pump
  • Use manufacturer-recommended lubricating oil only
  • Replace oil filter element every 6 months
  • Check V-belt tension and wear (if equipped)
  • Verify motor insulation resistance annually (≥1MΩ)
In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
